| Recommended Max PV Power (Wp) | 360 x 2 |
| Max DC Open Circuit Voltage (Vdc) | 60 |
| Max DC Input Current (Adc) | 12 x 2 |
| MPPT Tracking Accuracy | >99.5% |
| MPPT Tracking Range (Vdc) | 22-55 |
| Isc PV (absolute maximum) (Adc) | 14 x 2 |
| Maximum Inverter Backfeed Current to the Array (Adc) | 0 |
| Peak AC Output Power (Wp) | 550 (continuous) |
| Rated AC Output Power (Wp) | 500 |
| Nominal Power Grid Voltage (Vac) | 240 |
| Allowable Power Grid Voltage (Vac) | 211-264* |
| Allowable Power Grid Frequency (Hz) | 59.3 a 60.5* |
| THD | <3% (at rated power) |
| Power Factor (cos phi, fixed) | >0.99 (at rated power) |
| Rated Output Current (Aac) | 2.08 |
| Current (inrush)(Peak and Duration) | 24A, 15us |
| Nominal Frequency (Hz) | 60 |
| Maximum Output Fault Current (Aac) | 4.4A peak |
| Maximum Output Overcurrent Protection (Aac) | 10 |
| Maximum Number of Units Per Branch (20A) | 7 |
| Weighted Averaged Efficiency (CEC) | 95.50% |
| Night Time Tare Loss (Wp) | 0.11 |
| Over/Under Voltage Protection | Yes |
| Over/Under Frequency Protection | Yes |
| Anti-Islanding Protection | Yes |
| Over Current Protection | Yes |
| Reverse DC Polarity Protection | Yes |
| Overload Protection | Yes |
| Protection Degree | NEMA-6 / IP-66 / IP-67 |
| Ambient Temperature | -40°F to +149°F (-40°C to +65°C) |
| Operating Temperature | -40°F to +185°F (-40°C to +85°C) |
| Display | LED LIGHT |
| Communications | Power Line |
| Dimension (W-H-D) | 10.91”x5.20”x1.97”(277x132x50 mm) |
| Weight | 6.4 Ibs. (2.9 kg) |
| Environment Category | Indoor and outdoor |
| Wet Location | Suitable |
| Pollution Degree | PD 3 |
| Overvoltage Category | II(PV), III (AC MAINS) |
| Product Safety Compliance | UL 1741, CSA C22.2, No. 107.1 |
| Grid Code Compliance* | IEEE 1547, VDE-AR-N 4105*, VDE V 0126-1-1/A1, G83/2, CEI 021, AS 4777.2 & AS 4777.3, EN50438, ABNT NBR 16149/1615 |
