Upgrade your home energy management with our Wall-Mounted Energy Storage System—a compact, high-performance LFP (Lithium Iron Phosphate) battery solution designed for residential and light commercial use.
Featuring a scalable capacity from 2.56kWh to 16.07kWh, this home battery backup system delivers exceptional reliability with an impressive 6000+ cycle life at 80% DOD.
The space-saving wall-mount design, combined with a built-in intelligent BMS (Battery Management System), ensures maximum safety and effortless installation.
Whether you're seeking solar energy storage, backup power, or off-grid independence, this premium-grade battery system offers the flexibility to connect up to 15 units in parallel, providing a truly customizable energy storage solution for your evolving needs.
| Model | SMP-BU004 | SMP-BU005 | SMP-BU006 |
|---|---|---|---|
| Battery pack specifications | |||
| Nominal Voltage | 51.2VDC | ||
| Voltage Range | 43.2~57.6VDC | ||
| Nominal Capacity | 280Ah | 300Ah | 320Ah |
| Rated Energy | 14.336kWh | 15.36kWh | 16.384kWh |
| Communication Protocol | CAN / RS485 / RS232 / WIFI / Bluetooth | ||
| Cell Self-discharge | <5% / month | ||
| Supported Parallel Quantity | 1~15 PCS | ||
| DOD | 90% | ||
| Cycle Life | ≥6000 @ 25℃, 80% DOD | ||
| Maximum Charge & Discharge Current | 200A | ||
| IP Rating | IP20 | ||
| Installation Method | Floor-standing | ||
| Operating Temperature | 0~55℃ | ||
| Storage Temperature | -20~55℃ | ||
| Humidity | ≤80% | ||
| Product Dimensions | 850*530*250mm | ||
| Package Dimensions | 1000*630*470mm | ||
| Net Weight | 125kg | 130kg | 135kg |
