| Model | SUN-5K-SG01HP3-EU-AM2 |
| Battery Input Data | |
| Battery Type | Lithium-ion |
| Battery Voltage Range (V) | 160~700V |
| Max. Charging Current (A) | 37 |
| Max. Discharging Current (A) | 37 |
| Number of battery input | 1 |
| Charging Strategy for Li-Ion Battery | Self-adaption to BMS |
| PV String Input Data | |
| Max. DC Input Power (W) | 6500W |
| Max. DC Input Voltage (V) | 1000 |
| Start-up Voltage (V) | 180V |
| MPPT Range (V) | 150V-850V |
| Full Load DC Voltage Range (V) | 195-850 |
| Rated DC Input Voltage (V) | 600 |
| PV Input Current (A) | 20A+20A |
| Max. PV ISC (A) | 30A+30A |
| Number of MPPT / Strings per MPPT | 2/1 |
| AC Output Data | |
| Rated AC Output and UPS Power (W) | 5000W |
| Max. AC Output Power (W) | 5500W |
| Peak Power (off grid) | 1.5 times of rated power, 10 S |
| AC Output Rated Current (A) | 7.6/7.3 |
| Max. AC Current (A) | 13 |
| Max. Continuous AC Passthrough (A) | 40A |
| Output Frequency and Voltage | 50/60Hz; 3L/N/PE 220/380Vac, 230/400Vac |
| Grid Type | Three Phase |
| DC injection current (mA) | <0.5%1n |
| Efficiency | |
| Max. Efficiency | 97.60% |
| Euro Efficiency | 97.00% |
| MPPT Efficiency | 99.90% |
| Protection | |
| PV Input Lightning Protection | Integrated |
| Anti-islanding Protection | Integrated |
| PV String Input Reverse Polarity Protection | Integrated |
| Insulation Resistor Detection | Integrated |
| Residual Current Monitoring Unit | Integrated |
| Output Over Current Protection | Integrated |
| Output Shorted Protection | Integrated |
| Surge protection | Integrated |
| Output Over Voltage Protection | DC Type II / AC Type II |
| Certifications and Standards | |
| Grid Regulation | VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1, G98, G99, C10-11, UNE217002, NBR16149/NBR16150 |
| Safety EMC / Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
| General Data | |
| Operating Temperature Range (℃) | -40~60℃, >45℃ Derating |
| Cooling | Smart cooling |
| Noise (dB) | <55 dB |
| Communication with BMS | RS485; CAN |
| Weight (kg) | 35 |
| Size (mm) | 840W*345H*375D |
| Protection Degree | IP65 |
| Installation Style | Wall-mounted |
| Warranty | 5 years |
What markets are the solar products primarily shipped to?
The products are exported worldwide, serving key regions including Eastern Europe, North America, South America, Western Europe, Southern Europe, Northern Europe, Central America, South Asia, Oceania, Africa, and Southeast Asia.
How is consistent product quality guaranteed?
Consistent high quality is maintained by conducting a thorough pre-production sample evaluation before start of mass production, alongside standard final inspection workflows before any shipment is dispatched.
What core solar products can be ordered?
The complete product range features high-efficiency Solar Panels, Energy Storage Batteries, Integrated Solar Systems, Inverter Controllers, and Lithium battery energy storage units.
What are the key advantages of selecting these solar solutions?
Expertise in solar panel manufacturing combined with comprehensive energy solutions provides innovative residential and commercial alternatives, ensuring robust, one-stop systems tailored to individual power needs.
What delivery terms and payment options are accepted?
Accepted delivery terms include FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, and DES. Supported currencies cover USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY, and CHF via T/T, L/C, D/P, D/A, MoneyGram, Credit Card, PayPal, Western Union, and Escrow.
What is the warranty period for the hybrid inverter?
The hybrid solar inverter systems are backed by a standard 5-year warranty, offering reliable coverage and technical security for residential and commercial solar installations.
